ABE MTX D400/U_T2: 400W/RMS TV Transmitter with Direct Digital Synthesis (DDS) Modulator, N°1 double ASI input interface, N°3 Processor Board with DVB-T2 emission standard license (DVB-T/H and ISDB-T/Tb emission standard license as option), Linear & Non-Linear Digital Precorrector, LAN Interface (Web server, e-mail client and SNMP). Output power specified in the description is before output filter.
*The pictures shown related to this transmitter/transmitter system is only for illustration purpose. The the specific configuration the transmitter can be different from the picture
Digital outout power/rms 400 W
Housing 3 RU
Voltage 230V
Configuration "Compact"
Multistandard Multimode Digital & Analog Terrestrial TV Transmitter Line
ABE Elettronica is proud to present the MTX Series of Transmitters - Transposers - Gap-fillers for Digital and Analog Terrestrial Television Broadcasting (DVB-T2, DVB-T/H, ISDB-T/Tb, ATSC and other standards).
With the company's 30 years of experience in this field, the MTX Series is the ultimate in technology, quality and performance; it is desinged to take advantage of the excellence of the digital modulation systems to generate both Analog and Digital emissions.
This new MTX Series of Transmitters - Transposers - Gap-fillers brings together the highly efficient and reliable ABE MOS and LD-MOS broadband Power Amplifiers with state-of-the-art technological solutions.
KEY FEATURES
? Scalable architecture, capable of supporting both first and second generation analog and digital standards
? Multistandard analog modulation with digital processing (PAL/SECAM/NTSC B, G, D, I, K, K1, M and N standards supported
? Multistandard digital modulation (DVB-T2, DVB-T/H, ISDB-T/Tb and other standard)
? Available configurations: Modulator - Transmitter - Transposer - Transmodulator - Gap-filler...
? Wide choice of input interfaces (ASI - Ethernet for T.S. over IP - DVB-S/S2 Multistream receiver, Digital Terrestrial Receiver, Video/Audio analog...)
? RF output: UHF, VHF Band I and Band III
? Frequency Agile Direct Digital Synthesizer with 1Hz resolution
? Adaptive precorrection option
? High efficient 50V technology MOS and LD-MOS power amplifiers up to 20KW
? High degree of operational reliability: single or dual drive, passive stand-by systems (1+1 or N+1), multiple power amplifier versions
? User Friendly local and remote control includes "on-board" display, WEB server, SNMP and e-mail client
MAIN BENEFITS
Future proof high performance cost-effective solutions:
? Open platform design; to satisfy both today's and tomorrow's needs
? The ultimate in technology, quality, performance and reliability
? Low cost of ownership, low capital cost, running expenses & maintenance
Extreme flexibility:
? Complete range of options and configurations to satisfy any need
? Ultra-Compact versions, up to 1KW, integrating transmitter driver and power amplifier in a single rack drawer
With the company's 30 years of experience in this field, the MTX Series is the ultimate in technology, quality and performance; it is desinged to take advantage of the excellence of the digital modulation systems to generate both Analog and Digital emissions.
This new MTX Series of Transmitters - Transposers - Gap-fillers brings together the highly efficient and reliable ABE MOS and LD-MOS broadband Power Amplifiers with state-of-the-art technological solutions.
KEY FEATURES
? Scalable architecture, capable of supporting both first and second generation analog and digital standards
? Multistandard analog modulation with digital processing (PAL/SECAM/NTSC B, G, D, I, K, K1, M and N standards supported
? Multistandard digital modulation (DVB-T2, DVB-T/H, ISDB-T/Tb and other standard)
? Available configurations: Modulator - Transmitter - Transposer - Transmodulator - Gap-filler...
? Wide choice of input interfaces (ASI - Ethernet for T.S. over IP - DVB-S/S2 Multistream receiver, Digital Terrestrial Receiver, Video/Audio analog...)
? RF output: UHF, VHF Band I and Band III
? Frequency Agile Direct Digital Synthesizer with 1Hz resolution
? Adaptive precorrection option
? High efficient 50V technology MOS and LD-MOS power amplifiers up to 20KW
? High degree of operational reliability: single or dual drive, passive stand-by systems (1+1 or N+1), multiple power amplifier versions
? User Friendly local and remote control includes "on-board" display, WEB server, SNMP and e-mail client
MAIN BENEFITS
Future proof high performance cost-effective solutions:
? Open platform design; to satisfy both today's and tomorrow's needs
? The ultimate in technology, quality, performance and reliability
? Low cost of ownership, low capital cost, running expenses & maintenance
Extreme flexibility:
? Complete range of options and configurations to satisfy any need
? Ultra-Compact versions, up to 1KW, integrating transmitter driver and power amplifier in a single rack drawer
| Titel | Sorte | Größe | Herunterladen |
|---|---|---|---|
| MTX_Series-Srtandard-Information.pdf | 996.03KB | Herunterladen |
