Secced Reach Plus 1 Kit with Two-Stage Tripod & Fluid Head

The Reach Plus 1 Kit from Secced supports up to 15.2 lb loads and offers 0 to 7 steps of counterbalance for balancing your camera. The kit includes a two-stage carbon fiber tripod with a ground spreader and a 75mm aluminum ball fluid head with a pan bar. The head comes with a quick release plate and provides graded drag for quick pan and tilt adjustments. The tripod is designed with a matching 75mm bowl, and it is height adjustable from 21.7 to 63.8" with the head and ground spreader attached.

Key Features

• Carbon Fiber Tripod with Ground Spreader
• 75mm Fluid Head with 15.2 lb Payload
• 0 to 7 Steps of Counterbalance
• 0 to 3 Steps of Pan/Tilt Drag
• 21.7 to 63.8" Working Height

Configuration
Head: SC-DV6/75RP
Tripod: SC-DV/CF75D
Pan Bar:SC-PB10 (1pc)
Ground Spreader:SC-FS100

It has 8kg max. payload, compatible with most Mini-DV and HDV camcorder.
Improved drag system enhances smoothness of head movement, matching the quality of most famous brand. In addition, graded drag adjustment ensure fast change of tilt and pan drag.
Step-type counterbalance system help operator to balance the camera in a minute without changing over and over to look for the right amount of counterbalance.
Quick release mechanism ensures operator to quickly mount or dismount the camera on the head.
All main parts are made with high quality CNC machine. It enhances parts machining precision, ensures high reliability and improves fluid head performance substantially.
In order to enhance rigidity of plastic parts, high quality hard plastic is adopted to manufacture all plastic parts of fluid heads, especially those control elements (brake level, clamp level etc.), which results in considerable high durability of SECCED fluid heads.
75mm ball head, compatible with most 75mm tripod on the market.


Tripod: SC-DV/CF75D
Speed Locking system ensures quick setup of tripods and operators can get it ready for work within a minute.
Equipped with off ground and ground spreader
Carbon Fiber , light weight, solid and strong. it could support up to 20kg, good to use with various head to support DV/HDV cameras.

All plastic parts adopt the imported material, enhance the quality of spare parts and ensure high rigidity of tripods

SPECIFICATION

Reach Plus 1 Kit:

Weight: 6.4kg
Max Paylaod: 6.9kg
Height Range: 55-162mm
Bowl Diameter: 75 mm
Transport Length: 86cm


Head:

Weight: 2.5 kg
Counterbalance: 0-7 steps
Sliding range-plate: 110mm
Grades of tilt drag: 0-3
Grades of pan drag: 0-3
Tilt range: -75°/+90°
Tripod fitting: 75mm

Payload

C.O.G (mm) Min Payload (kg) Max Payload (kg)
50 0.00 6.90
75 0.00 5.60
100 0.00 4.71
125 0.00 4.13

Tripod:

Weight (With Ground Spreader): 3.7kg
Max. Payload: 20kg
Height Range (With Ground Spreader): 40-147cm
Height Range (With Off Ground Spreader): 49-142cm
Bowl Size: 75mm
Transport Length: 71cm
Extension: Double
Material: Carbon Fiber
