General specification RVR Splitters:
50 Ohm
Frequency Range 87.5-108 MHz
VSWR 1.05:1 Max
Insertion Loss 0.05 dB Max
Connectors N-7/16-7/8""-1+5/8""-3+1/8""-4+1/8""
In according to the working power
Max Power Input From 100 Watts to 40 KW
In according to the model
Number of outputs 2-8 (In according to the model)
Length approx. 1600 mm
Diameter external tube From 40 to 120 mm
In according to the working power
Mounting With special pipe clamp
Working Temperature -20°C ÷ +50°C
Colour Enamel gray ral 7001
Materials Aluminium, Brass, Copper, PTFE, Stainless Steel,
Silvering (min 12μ thickness)""
