Frequency range 2300-2500MHz
Gain at center frequency 23,7dBi
-3dB beam width 9,8°
VSWR max on full band 1,8:1
Max power handling 50W
Impedance 50 ohms
Polarization Linear / Vertical
Other polarization available on request
Connector N-female
Mechanical specifications:
Dish material UV resistant ABS plastic
Radome material UV resistant ABS plastic
Mounting hardware Stainless steel
All screws 8mm
Mast clamp 25-65mm
Temperature -40 - +80°C
Antenna diameter total 880 mm
Gain at center frequency 23,7dBi
-3dB beam width 9,8°
VSWR max on full band 1,8:1
Max power handling 50W
Impedance 50 ohms
Polarization Linear / Vertical
Other polarization available on request
Connector N-female
Mechanical specifications:
Dish material UV resistant ABS plastic
Radome material UV resistant ABS plastic
Mounting hardware Stainless steel
All screws 8mm
Mast clamp 25-65mm
Temperature -40 - +80°C
Antenna diameter total 880 mm
