* When connected to AK-UC3000 or AK-HC5000.
Specifications:
| Power Supply | DC 12 V (supplied from camera or XLR) | |
|---|---|---|
| Power Consumption | 18 W | |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) | |
| Operating Humidity | 10% - 85% (no condensation) | |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) | |
| Weight | Approx. 2.6 kg (5.73 lbs.) (not including hood) / Approx. 3.0 kg (6.61 lbs.) (including hood) | |
| Dimensions (W x H x D) | 340 mm x 234 mm x 193 mm (13-13/32 inches x 9-7/32 inches x 7-5/8 inches) (not including hood) 340 mm x 234 mm x 231 mm (13-13/32 inches x 9-7/32 inches x 9-1/8 inches) (including hood) |
|
| Display Panel | 22.9cm (9.0 inches) | |
| Number of Pixels | 1920 x 1080 (FHD) | |
| Display Color | Approx. 16.77 million colors | |
| Operation | <POWER> switch, <MENU> button, <SELECT> dial button, <F1>/<F2>/<F3>/<F4> buttons, <BRIGHT> knob, <CONTRAST> knob, <PEAKING> knob, <INPUT> switch |
|
| Connector | Camera I/F connector (D-sub 29 pins x 1) SDI IN connector (BNC x 1) DC IN connector (XLR 4 pins x 1) | |
| Supported Signal Format | CAM | 1080/59.94i, 1080/50i |
| SDI | 1080/59.94p, 1080/50p, 1080/59.94i, 1080/50i, 720/59.94p, 720/50p | |
| Titel | Sorte | Größe | Herunterladen |
|---|---|---|---|
| Panasonic-AK-HVF100G-_-operating-instructions.pdf | 90.78KB | Herunterladen |
PA-AK-PLV100GSJ
Bitte erfragen Sie unsere Lieferzeit
33.500,00 EUR
30.150,00 EUR
