On-device buttons make it easy to select and set the display layout—simply cycle through pre-set configurations. Set up display positions, fine tune bezels, and also troubleshoot with ease, by accessing the built-in or pre-saved images directly from the appliance, together with display identification information that includes the ID number and the resolution of each output.
Compact design fits anywhere
Fit three QuadHead2Go appliances horizontally or ten appliances vertically—in a standard 19-inch rack. Simply place the appliance on the desktop, workstation, or rack, and it’s ready to use. Need to mount your QuadHead2Go appliance to your monitor instead? Conveniently mount it to your display with the available VESA bracket.
Scale your video wall. Easily and infinitely.
Rotate and position outputs independently from one another
Design modern and artistic video wall layouts with free rein—each output can have its own resolution, be independently rotated (90, 180, and 270 degrees), cropped, upscaled, downscaled, and positioned anywhere.
Create or expand large-scale video wall solutions
Expand to a video wall configuration of any size by using multiple QuadHead2Go appliances. Fashion countless forms of setups—arrange displays in 4x1, 1x4, 2x2, 3x1, 1x3, 2x1, or 1x2 rectangular configurations, in portrait or landscape, or other non-rectangular/artistic configurations—and combine/scale them to create large-scale video walls.
Proven video wall ecosystem
Drive up to 64 1920x1080p60 displays and create captivating video walls by pairing QuadHead2Go multi-monitor controllers with Matrox LUMA or Matrox D-Series graphics cards.
| Part Number |
Q2G-DP4K |
| Form Factor |
Standalone appliance |
| Connectivity | |
| Video Input |
Number of channels: Formats: |
| Video Output |
Number of channels: Formats: |
| Network Connector |
1x RJ45 |
| Multi-Unit Support |
Yes |
| Performance | |
| Maximum Video Resolutions |
Support for custom resolutions; contact Matrox for details. |
| Memory |
1 GB |
| Video Input Resolutions |
3840x2160 @60Hz Other input resolutions including 8Kx8K are supported. Contact Matrox for more details. |
| Video Output Resolutions |
1920x1080 @60Hz Other output resolutions are supported. |
| Color Space and Chroma Sub-Sampling |
Input: Output: |
| Video and Audio Processing | |
| Supported Configurations |
2x2 (default), 4x1, 3x1, 2x1, 1x2, 1x3, 1x4 in both landscape and portrait modes and other non-rectangular/artistic configurations |
| Non-Rectangular/Artistic Video Walls |
Yes |
| Clone Mode |
Yes |
| Rotation (output) |
Yes. Support for 90, 180, 270 degrees |
| Bezel Management |
Yes |
| Video Scaling |
Yes |
| Video Cropping |
Yes |
| Stretched Desktop Support |
Yes |
| HDCP Support |
Yes |
| Audio Output Format |
AAC, PCM, Stereo, and Mono |
| Audio Sampling Frequency |
44.1 KHz and 48 KHz |
| Network | |
| IP Addressing |
IPv4 IPv6* DHCP (default) and static IP *IP version 6 support coming soon. Please view Release Notes for latest updates or contact Matrox for more details |
| Physical | |
| Product Dimensions |
5.50 (W) x 1.25 (H) x 7.13 (D) inches |
| Unit Weight |
1.089 lbs / 494 g |
| Cooling |
Fanless |
| Power Supply Unit |
100-240 V a.c. in, 12 V d.c. out, 42 W |
| Hardware & Software | |
| Hardware Included |
4 x 6 feet power cables for US, EU, UK, Aus/Nz |
| Accessories (sold separately) |
Secure Cable Solution (SK-Q2G-A) VESA bracket (RMK-6BRKT-A) Rack Mount Kit (RMK-19TR-A) |
| Software |
Matrox PowerWall (free download) |
| Environmental | |
| Operating Conditions |
Temperature: 0 to 45 degrees Celsius Humidity: 20% to 80% non-condensing |
| Storage Conditions |
Temperature: -40 to 70 degrees Celsius Humidity: 5% to 95% non-condensing |
| Power Consumption |
15W |
| General | |
| EMC/EMI Device Class |
Class A |
| EMC/EMI Compliance |
CE (EU) FCC (US) ICES-3 (Canada) KC (Korea) |
| Environmental Compliance |
China RoHS EU RoHS REACH |
| Warranty |
Three-year limited warranty with free telephone support |
